Variable area flow meter model EA
Flow range H2O, 20°C:
min 2 – 15 mL/min
max 0.5 – 2.5 L/min
Flow range air, 1.013 bar(a), 20°C:
min 0.1 – 0.8 NL/min
max 15 – 75 NL/min
Applications
heat treatment ovens
automatic welding lines
Industrial plastic tube variable area flow meter with alarm model EA
Industrial plastic tube variable area flow meter with alarm model EA
Kytola’s acrylic plastic tube flow meter model EA is a dependable industrial flow meter for applications where continuous flow control is required.The flow meter is aimed for measuring and monitoring liquid and gas flows.
Kytola’s model EA measures and monitors liquid and gas flows in applications where continuous flow control is required. The acrylic flow meter EA is equipped with an adjustable alarm to further increase its monitoring performance. The model EA measures and monitors liquid and gas flows with high precision. The finess of the flow meter lies in the skillfully manufactured components which ensure its accuracy and reliable operation in industrial applications. The body is made in one piece of precision-machined acrylic which prevents leaks as no attachments are required.
Special emphasis has been put into its user friendliness. The flow rate is easily read at a glance as the scales are clear. The flow meter unit is rapid to assemble and disassemble whenever maintenance is needed.
This variable area flow meter is an excellent and affordable choice for industrial flow measurement needs.
