Home Products Constant flow regulator model 2851

Constant flow regulators for gases

Constant flow regulators for water

Constant flow regulator model 2851

Flow range H₂O, 20°C:
min 15 – 80 mL/min
max 0.5 – 3.5 L/min

Flow range air, 1.013 bar(a), 20°C:
min 0.5 – 2.5 NL/min
max 15 – 110 NL/min

Typical applications:
control of seal waters
control of flush waters
water or air purging
level measurement in tanks

Ask more about this product

Download datasheet Model 2851 (373.42 KB pdf)

Technical data

Technical data

Model	2851
Max. flow USGPM (L/min)	H₂O: 45 USGPM (3.0 L/min); Air: 240 SCFH at 87 psig (100 NL/min air at 6 barg)
Nominal flow	H₂O: 36 USGPH (2.3 L/min); Air: 240 SCFH at 87 psig (100 NL/min at 6 barg)
Max. pressure difference	290 psi (20 bar)
Max. static pressure	290 psi (20 bar), *435 psi / 85°F (30 bar / 30°C)
Min. pressure difference	29 psi (2 bar)
Connections G/NPT	G 1/4″ or NPT 1/4″
Max. temperature	165°F (75°C) with acrylic flow tube, 176°F (80°C) with Grilamid flow tube
Weight	2 lbs (0.85 kg)
Body	AISI 316
Spring	AISI 316
Membrane	EPDM
Membrane plate	AISI 316
Seals	Nitrile (*Viton®, EPDM)
Mesh	PTFE
Installation position	Vertical
*) Special construction on request
