Flow Meter Selector Tool

You can use this tool to sort out the best suitable flow meter model(s) according to your specific process requirements.

0,1 - 1 NL/min

1 - 10 NL/min

10 - 100 NL/min

100 - 1000 NL/min

1000 - 15 000 NL/min

Flow medium

Please select your process medium or the closest equivalent option from the drop-down menu.

Kytola supplies flow meters for various different liquids used in industrial applications. Fluid parameters that affects to the flow meter selection are for example the density, the viscosity and the chemical compatibility. Please contact Kytola for a further support regarding your specific process fluid.

Flow rate

All Kytola standard gas flow meters are calibrated for air at +20°C/101,3 kPa. We can also supply a tailor-made scale for your process specific operating conditions. The slide button enables you to calculate an equivalent flow rate value according to your operating conditions. This value is comparable to our standard air scales. Another option is to select an air flow range (+20°C/101,3 kPa) from the drop-down menu.

Calculate Select

Equivalent flow rate calculation

Type the flow rate (Q), select the gas from the drop-down menu or select Other gases and type the gas specific gravity (SG) value, type either the inlet or the outlet normal operating pressure depending on which one is known and stable and type the normal operating temperature. Please note that it is important to know the real pressure and temperature inside the metering tube. If the inlet pressure is known the optional flow adjusting valve must be in outlet side of the meter. If the outlet pressure is known the valve must be in inlet side. Qeqv value is comparable to our standard air scales and you can use it to find potential flow meter model(s). Please contact Kytola to confirm the model selection and the exact available scale range(s).

Q =

Gas =

Specific gas gravity =

p =

T =

Q_eqv= NL/min air at +20°C, 101,3 kPa

Water flow rate

Please select the range that covers your process flow rate requirements.

Seal water flow rate

Please select the range that covers your process flow rate requirements.

Air flow rate

Flow adjusting valve

If you turn the slide button on you will only see models that are equipped with a flow adjusting valve. If you also want to see models without a flow adjusting valve, please keep the slide button turned off.

with needle valve

Output

You can select the optional flow alarm and/or mA transmitter feature to see models that are available with these accessories.

ma transmitter

Need help? Contact our sales

Products found:

Flow rate (min / max):
Water:	0.002/6.5 L/min
Air:	0.1/220 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Air:	0.2/7.5 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	0.5/30 L/min
Air:	20/1000 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	7.5/100 L/min
Air:	200/2500 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	0.002/2.5 L/min
Air:	0.1/90 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	5/80 L/min
Air:	140/2500 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	8/370 L/min
Air:	350/14000 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	0.3/30 L/min
Air:	15/900 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	7.5/120 L/min
Air:	200/2800 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Air:	200/3000 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	0.002/3.5 L/min
Air:	0.1/110 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	7.5/400 L/min
Air:	300/12000 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	0.4/32.5 L/min
Air:	15/1100 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	0.4/30 L/min
Air:	15/700 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	1.25/32.5 L/min
Air:	40/1100 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	1.25/30 L/min
Air:	40/700 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	1/30 L/min
Air:	40/900 NL/min
at	+20°C / 101,3 kPa

Flow rate (min / max):
Water:	0.015/6.7 L/min
Air:	1/200 NL/min
at	+20°C / 101,3 kPa
